Device #

OTP Phase Configuration

Switching Frequency

I2C Address

Rail Info

(Voltage and Phases)

Current Limit

Start-up Delay

Shut-down Delay

Control Pin

PGOOD

Mode

LP8758-B0

4 PH

3 MHz

0x60

1100mV (DCDC 4PH)

16 A

0 ms

0 ms

EN1

Unmasked

LP8758-C0

4 PH

3MHz

0x60

800mV (DCDC 4PH)

16 A

0 ms

0 ms

EN1

Unmasked

LP8758-C3

3 + 1 PH

3 MHz

0x60

900mV (DCDC 3PH)

900mV (DCDC 1PH)

12 A

 3 A

0 ms

0 ms

0 ms

0 ms

EN1

EN1

masked

masked

LP8758-C4

3 + 1 PH

3 MHz

0x60

800mV (DCDC 3PH)

800mV (DCDC 1PH)

12 A

 3 A

0 ms

0 ms

0 ms

0 ms

EN1

EN1

masked

masked

LP8758-E0

1+1+1+1 PH

3 MHz

0x60

1000 mV (DCDC 1PH)

2500 mV (DCDC 1PH)

1200 mV (DCDC 1PH)

1800 mV (DCDC 1PH)

2.5 A

4.5 A

3.5 A

4.5 A

0 ms

0 ms

5 ms

0 ms

5 ms

5 ms

0 ms

5 ms

EN1

EN1

EN1

EN1

masked

Masked

masked

masked

LP8758-E2

1+1+1+1 PH

3 MHz

0x60

1800 mV (DCDC 1PH)

900 mV (DCDC 1PH)

1000 mV (DCDC 1PH)

1500 mV (DCDC 1PH)

2.5 A

2.5 A

2.5 A

2.5 A

0 ms

0 ms

0 ms

0 ms

5 ms

5 ms

5 ms

5 ms

EN1

EN1

EN2

EN2

masked

Masked

masked

masked

LP8758-E3

1+1+1+1 PH

3MHz

0x60

900mV (DCDC 1PH)

1200 mV (DCDC 1PH)

1800 mV (DCDC 1PH)

2700 mV (DCDC 1PH)

4.5 A

3.0 A

3.0 A

3.75 A

2 ms

3 ms

3 ms

4 ms

0 ms

0 ms

0 ms

0 ms

EN1

EN1

EN1

EN1

masked

Masked

masked

masked

LP8758-E6

1+1+1+1 PH

3 MHz

0x60

1800 mV (DCDC 1PH)

800 mV (DCDC 1PH)

800 mV (DCDC 1PH)

800 mV (DCDC 1PH)

3.0 A

3.0 A

3.0 A

3.0 A

9 ms

1 ms

6 ms

0 ms

2 ms

8 ms

4 ms

9 ms

EN2

EN1

EN1

EN2

masked

Masked

masked

masked

LP8758-E7

1+1+1+1 PH

3MHz

0x70

3300mV (DCDC 1PH)

1150 mV (DCDC 1PH)

3300 mV (DCDC 1PH)

1100 mV (DCDC 1PH)

3.0 A

3.0 A

3.0 A

3.0 A

3 ms

4 ms

3 ms

0 ms

0 ms

9 ms

10 ms

13 ms

EN1

EN1

EN2

EN2

masked

Masked

masked

masked

LP8758-F0

2 + 2 PH

3 MHz

0x60

900mV (DCDC 2PH)

900mV (DCDC 2PH)

9 A

9 A

0 ms

0 ms

0 ms

0 ms

I2C

I2C

unmasked

unmasked
